Elevate Slim

Built by DigiFarm VBN with real RTK users in mind, the Elevate Slim is a smarter, simpler modem designed to keep your operation connected without the hassle. With easy transfer between machines, a clean roof-mounted setup, and cloud-based remote management, it delivers a reliable, fully integrated RTK experience from install to daily use.

The Elevate Slim is compatible with any brand of agricultural GPS receiver, giving you colorblind brand flexibility across your entire fleet. Through DigiFarm’s portal, customer support and dealers can remotely manage mount points and settings, making setup fast and efficient. In just seconds, your Elevate Slim can be connected and ready to work. DigiFarm also offers the custom cabling needed to connect with the receiver of your choice, making installation seamless from start to finish.

Advantages

  • Easily move elevate from machine to machine
  • Easy mag-mount roof installation
  • Works with any brand of GPS receiver, including John Deere Star Fire and Integrated receivers.
  • Over-the-air firmware updates
  • Easily change receiver mount points with assistance from our support team
  • No data overages
  • Eliminate cab clutter

Size: 5 inches x 7 inches (127.00mm x 177.8 mm)
Weight: 1 lbs 8 oz
Operating Temperature: -40 – 158F (-40 – 70 C)

Power at 12 VDC: 1.7W at 12 VDC
Input Voltage range: 12-24 VDC
Connector: 12 pin Deutsch
Environmental: IP67, when correct cables are connected

Data Interface
Two RS232 interfaces operating 9,600 to 115,000 bps
Native Deere radio emulation

Cellular
Carriers: AT&T, Verizon, T-mobile/US Cellular
Countries: United States and Canada (only Verizon in Canda with a roam any carrier plan)
Cellular Bands:
4G LTE-FDD:​ B2, B4, B5, B12, B13, B14, B66, B71
3G HSPA+:​ B2, B4, B5

Transmit Power:
4G: 23.0 dBm ± 0.5 dBm
3G: 23.5 dBm ± 0.5 dBm

Receive Sensitivity:
4G: -102.0 dBm (@ 5 MHz BW)
3G: -112.0 dBm (@ 5 MHz BW)

Quick Reference Cards: For basic settings and first time set ups
